Ovation 2WL

Useful for times when DMX lighting isn’t needed, this effective utility light is powered by direct line voltage and can be dimmed via off-the-shelf phase-cut or triac dimmers. Projecting a soft flood light that minimizes shadows, Ovation 2WL offers selectable 3200K, 4000K, and 5600K color temperatures that provide wide-spectrum, high-CRI lighting.


Specifications

Optical

  • Light Source: 960 LEDs (CW, WW)
  • Color Temperature (3200k): 3217 K
  • Color Temperature (4000k): 3960 K
  • Color Temperature (5600k): 5584 K
  • CRI (3200K): 95.3
  • CRI (4000K): 95.2
  • CRI (5600K): 94.0
  • Beam Angle: 107.4°
  • Field Angle: 158.7°
  • Lumens (3200k): 10,564
  • Lumens (4000k): 10,954
  • Lumens (5600k): 11,328
  • Illuminance 3200k): 158 lux @ 5 m
  • Illuminance (4000k): 164 lux @ 5 m
  • Illuminance (5600k): 169 lux @ 5 m

Dynamic Effects

  • Dimmer: External Dimmer (phase cut or triac compatible)
  • On-board Color Temperature Selection

Construction / Physical

  • Dimensions: 17.51x 11.06 x 5.47 in (445 x 281 x 139 mm)
  • Weight: 10.2 lb (4.6 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum alloy
  • Accessory Holder/Gel Frame Size: 14.375 x 8.50 x 0.125 in (365.125 x 216 x 3.175 mm)

Connections

  • Power Connection: Edison (local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Cable Length (power): 5 ft (1.5 m)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 13 units @ 120 V; 21 units @ 208 V; 23 units @ 230 V
  • Power and Current: 103 W, 0.91 A @ 120 V, 60 Hz
  • Power and Current: 99 W, 0.55 A @ 208 V, 60 Hz
  • Power and Current: 98 W, 0.51 A @ 230 V, 50 Hz
  • Breaker Size: T2.5 A, 350 V

Certifications / Qualifications

  • CE, MET, FCC, RoHs
  • IP Rating: IP20, dry location
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included

  • Ovation 2WL
  • Seetronic Powerkon power cable
  • Omega Bracket with mounting hardware

Optional Accessories

  • Professional Clamps: CTC-50HC, CTC-50HCN
