Maverick MK2 Spot

Maverick MK2 Spot is a stunningly bright moving yoke spot featuring a 440 W LED engine, precision engineered optics, CMY + CTO color mixing, two 6-position rotating slot and lock gobo wheels, a 7-position + white color wheel, variable frost, 3-facet prism and 14.7º – 40.5º zoom range. Control it as you see fit with DMX, sACN, Art-Net, or W-DMX.

parnelli_2016

At a Glance

  • Fully featured 440W LED yoke spot fixture including CMY+CTO color mixing, a color wheel, zoom optics, and two rotating gobo wheels

  • 16-bit dimming of master dimmer for smooth control of fades

  • Variable CMY+CTO color mixing system to create a wide pallet of colors

  • Two rotating, indexing and interchangeable slot and lock gobo wheels

  • DMX , W-DMX, sACN, and Art-Net for full flexibility of control options

  • 14.7° to 40.5° zoom angle for variable beam sizes

  • Iris, 3-facet prism, and frost for beam control

  • True 1 compatible power input

  • Battery backup display with auto rotate depending on fixture orientation

Specifications

Optical

  • Light Source: 1 LED (CW) 440 W, (5.6 A), 6808 K, 50,000 hours life expectancy
  • Color Temperature (at full): 7101 K
  • Front Lens diameter: 116 mm
  • CRI: 73
  • Beam Angle: 12° to 35.6°
  • Field Angle: 14.7° to 40.5°
  • Zoom Angle: 14.7° to 40.5°
  • Lumens - Source: 28,000
  • Lumens - Output: 18,506
  • Illuminance (13°): 20,200 lux @ 5 m
  • Illuminance (37°): 2,731 lux @ 5 m
  • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

Dynamic Effects

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colors: 7 + white, split colors, continuous scroll at variable speeds
  • Colors: CMY flags, CTO flag
  • Gobos (1): 6 + open (6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobos (2): 6 + open (6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobo Size (1) : Gobo Wheel 1 (rotating): 32 mm (outside), 28 mm (image), 3.3 mm (max. thickness)
  • Gobo Size (2) : Gobo Wheel 2 (rotating): 32 mm (outside), 28 mm (image), 3.3 mm (max. thickness)
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Focus: Motorized
  • Frost: Motorized
  • Iris: Motorized
  • Prism: 3 Facets, motorized, rotating
  • Strobe Rate: 0 to 20 Hz
  • Move-in-Black: Yes
  • Dim Curves: 4

Construction / Physical

  • Dimensions: 15.1 x 9.8 x 26.4 in (385 x 250 x 671 mm)
  • Weight: 62.8 lb (28.5 kg)
  • Exterior Color: Black
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Data Connectors: 3- and 5-pin XLR, Neutrik
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: Art-Net, sACN, DMX, W-DMX
  • DMX Channels: 24 or 32
  • Art-Net Channels: 24 or 32
  • Modes/Personalities: 2 personalities (24, 32)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 740 W, 6.01 A @ 120 V, 60 Hz
  • Power and Current: 723 W, 3.63 A @ 208 V, 60 Hz
  • Power and Current: 700 W, 3.33 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET
  • IP Rating: IP20, dry location

What's Included

  • Maverick MK2 Spot
  • Seetronic Powerkon IP65 power cord
  • Omega bracket with mounting hardware

Required Accessories
