Rogue R2X Beam

Rogue R2X Beam is the light cannon of the Rogue series, boasting an intense 134,000 lux at 15 meters from its 231 W Osram Sirius lamp. This fully-featured beam can be focused down to 1 degree for extremely focused aerial effects, and comes with 14 fixed colors in a fully scrollable, variable speed color wheel, which also provides split-colors perfectly. Additionally, the unit features individually controllable and overlapping 8 and 5-facet prisms for an endless supply of creative and dynamic beam looks. Frost and focus options ensure even light distribution and the unit is equipped with RDM and DMX protocols.


At a Glance

  • Fully featured, high powered beam fixture with a single color wheel, single static gobo wheel, and overlapping prisms

  • Fast and precise movement of Pan and Tilt functions

  • Individually controllable and overlappable 8 and 5-facet prisms

  • Frost for even light distribution

  • Tight 1° beam for extremely focused areal effects

  • RDM Enabled for remote addressing and trouble shooting

  • 17 static gobos for massive visual impact

Specifications

Optical

  • Light Source: Osram Sirius 231 W lamp, 7900 K, 2,000 hours life expectancy
  • Color Temperature (at full): 7293 K
  • Beam Angle: 1.8°
  • Field Angle: 3.7°
  • Lumens – Source: 10,500
  • Lumens - Output: 7,821
  • Illuminance (total): 150,684 lux @ 15 m

Dynamic Effects

  • Pan and Tilt: 540°/270
  • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
  • Colors: 14 + white, split colors, continuous scroll at variable speeds
  • Gobos: 17 + open (17 metal), continuous scroll at variable speeds
  • Dimmer: Motorized
  • Shutter/Strobe: Motorized
  • Focus: Motorized
  • Frost: Motorized
  • Prism: 5 Facets, motorized, rotating
    8 Facets, motorized, rotating
  • Strobe Rate: 0 to 20 Hz
  • Move-in-Black: Yes

Construction / Physical

  • Dimensions: 16.1 x 12.8 x 19.2 in (409 x 327 x 490 mm)
  • Weight: 45.4 lb (20.6 kg)
  • Exterior Color: Black
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: Edison (Local) plug to Neutrik
  • Power Input: Neutrik powerCON
  • Data Connectors: 3- and 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: DMX, RDM
  • DMX Channels: 16 or 19
  • Modes/Personalities: 2 personalities (16, 19)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 384 W, 3.18 A @ 120 V, 60 Hz
  • Power and Current: 378 W, 1.81 A @ 208 V, 60 Hz
  • Power and Current: 382 W, 1.61 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET
  • IP Rating: IP20, dry location
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included

  • Rogue R2X Beam
  • Neutrik powerCON power cord
  • 2 Omega brackets with mounting hardware
