Rogue Outcast 3X Wash
An IP65-rated LED wash fixture featuring a fast zoom, nine pixel-mappable zones, and 37 powerful RGBW LEDs that deliver excellent color blending and a strong output.
Perfect for a wide range of applications from touring and outdoor festivals to on-camera use, especially in environments demanding durability against the elements.
-
Generates a powerful, even field of light from thirty-seven 25 W RGBW LEDs.
-
Offers a versatile zoom range from a tight 9.3° beam to an expansive 62.6° wash.
-
Built with a rugged yet lightweight aluminum and magnesium alloy IP65-rated housing.
-
Ensures flicker-free on-camera operation with selectable PWM and a calibrated white setting.
-
Achieves exceptionally smooth fades with 16-bit dimming and six distinct dimming modes.
-
Provides flexible programming with four DMX personalities and RDM for remote setup.
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
Rogue Outcast 3X Wash
Rogue Outcast 3X Wash brings a fast zoom from beam to wash, the power to punch through fog or haze, and alloy-armored IP65-rated durability that withstands the elements, from dust to rain, indoors or out. Offering the convenience of selecting simple or complex DMX personalities, this versatile workhorse suits the widest range of applications, including on-camera use with its user selectable calibrated white. 37 bright 25W RGBW LEDs occupy 9 pixel-mappable zones and produce excellent color blending and fades with 16-bit master and individual dimming.
Features
RGBW LED Wash with Zoom
A versatile and fully-featured yoke wash fixture with rich RGBW color mixing, zoom, and an IP65 rating.
Durable and Lightweight Body
Constructed with a rugged yet lightweight aluminum and magnesium alloy body built for demanding environments.
16-Bit Dimming
Achieve exceptionally smooth fades with high-resolution dimming for the master dimmer and individual colors.
High-Output RGBW LEDs
Equipped with thirty-seven 25-watt RGBW LEDs for an incredibly bright and powerful output.
5-Pin DMX Connections
Features professional 5-pin DMX input and output for secure, reliable control in any lighting rig.
Nine-Zone LED Control
Create dynamic visual looks and pixel-mapping effects with nine individually controllable zones of LEDs.
Fast and Smooth Movement
Delivers quick, fluid, and precise pan and tilt movement for rapid repositioning.
RDM Enabled
Allows for remote addressing, configuration, and troubleshooting directly from an RDM-compliant controller.
Selectable PWM Options
Ensures flicker-free performance on camera with selectable Pulse Width Modulation settings.
OLED Display
An easy-to-read OLED display provides a simple and effective menu for onboard adjustments.
Calibrated White
Includes a user-selectable calibrated white that delivers a consistent 7500 K color temperature at full output.
Six Distinct Dimming Modes
Choose from six different dimming modes for advanced control and customized fades.
Versatile DMX Profiles
Offers both simple and complex DMX channel profiles for ultimate programming versatility.
USB-C Software Port
A convenient USB-C port allows for fast and easy software uploads to keep the fixture current.
Complete Your Rig
Specifications
Optical
-
Light Source
37 LEDs (quad-color RGBW) 25 W, (1.5 A), 50,000 hours life expectancy
-
Color Temperature (range)
2800 to 10000 K
-
Beam Angle
9.3° to 33.9°
-
Field Angle
11.6° to 49.5°
-
Cutoff angle
13.1° to 62.6°
-
Zoom Angle
9.3° to 62.6°
-
Lumens – Source
17,000
-
Lumens – Output
13,440
-
-
Illuminance
-
Illuminance (9.3°)
18,260 lux @ 5 m
-
Illuminance (62.6°)
1,556 lux @ 5 m
-
-
Illuminance
-
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
-
Pan and Tilt
540°/270°
-
Pan and Tilt Ranges
180°, 360°, 540° Pan/90°, 180°, 230° Tilt.
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Zoom
Motorized
-
Strobe Rate
0 to 25 Hz
-
Standalone Color Mixing
Yes
-
Color Temperature Presets
Yes
-
Dim Curves
4
-
Built-in Automated Programs
Yes
-
Customizable Programs
No
-
Recall Custom Programs
No
Construction/Physical
-
Dimensions
15.59 x 11.73 x 17.20 in (396 x 298 x 437 mm)
-
Dimensions (shipping size)
23.62x 14.17 x 18.70 in (600 x 360 x 475)
-
Weight
38.2 lb. (17.38kg)
-
Exterior Color
Black
-
Housing Material
High-impact flame-retardant polymer.
Connections
-
Power Connection
Edison (local) plug to Seetronic PowerKON IP65
-
Power Input
Seetronic PowerKON IP65
-
Power Output
Seetronic PowerKON IP65
-
Data Connectors
5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
21, 62, 71, 107
-
Modes/Personalities
4 personalities
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
2 units @ 120 V; 3 units @ 208 V; 3 units @ 230 V
-
Power and Current
711 W, 5.98 A @ 120 V, 60 Hz
-
Power and Current
701 W, 3.40 A @ 208 V, 60 Hz
-
Power and Current
695 W, 3.07 A @ 230 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET, FCC, FCC, UKCA
-
IP Rating
IP65, temporary outdoor/wet use
-
-
Noise Levels
-
Noise Level (Idle)
22.8 dB(A) @ 1 m
-
Noise Level (Auto)
47.5 dB(A) @ 1 m
-
Noise Level (Eco)
34.3 dB(A) @ 1 m
-
Noise Level (Full)
47.3 dB(A) @ 1 m
-
Noise Level (Max)
37.2 dB(A) @ 1 m
-
-
Noise Levels
-
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories
- Professional Clamps: CTC-50HC, CTC-50HCN
- Safety Cable: SC-08
- Seetronic IP65 PowerKon cables
- DMX Cables
- UPLOAD 08 software uploader
What's Included
- Rogue Outcast 3X Wash
- Seetronic PowerKon IP65 power cord
- (2) 140D Omega brackets with mounting hardware
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
Manuals | Rogue Outcast 3X Wash – Quick Reference Guide | Download |
DMX | Rogue Outcast 3X Wash – DMX Chart | Download |
Manuals | Rogue Outcast 3X Wash – User Manual | Download |
Other | Rogue Outcast 3X Wash – IES Files | Download |
Photometrics | Rogue Outcast 3X Wash Photometrics Report | Download |
Drawings | Rogue Outcast 3X Wash – 2D CAD file | Download |
Manuals | Rogue Outcast 3X Wash – 3D CAD file | Download |
Case Studies | Rogue Outcast 3X Wash – Acoustic Report | Download |
Learn How To Use Your Rogue Outcast 3X Wash
Explore these detailed videos showcasing setup, features, and creative applications for this product.
-
Lighting a 360° Circus Tour Across France | Imperial Tour
Discover how a full CHAUVET Professional rig empowers the Imperial Show’s 360° circus tour across France. IP-rated fixtures provide the reliability and creative power needed to overcome a humid, dust-heavy environment and deliver a spectacular experience every time.
Rogue Outcast 3X Wash FAQ’s
Yes, it is built with a durable, weather-resistant body designed to withstand the elements. It is protected against dust and rain, making it a reliable lighting choice for outdoor concerts, festivals, and events.
This versatile fixture can quickly zoom from a tight, focused beam of light to a very wide, soft wash. It also features nine controllable zones that allow for vibrant, pixel-style patterns and dynamic color effects.
Yes, it is ideal for on-camera use. It is designed to be flicker-free for video and includes a calibrated white setting to ensure colors look natural and consistent during filming, streaming, or broadcast events.
