    Available in 4 different lengths

    IP Flex Extension

    A 3-pin, IP67-rated extension cable featuring secure locking connectors, available in various lengths to reliably extend power or data connections.
    Ideal for outdoor event production, architectural installations, or any environment where connections must be protected from dust and water.

    Read More Read Less
    Read More Read Less
    LengthSKUDescription
    5FT
    IPFLEXEXT5FT
    IP Flex Extension – 5FT
    15FT
    IPFLEXEXT15FT
    IP Flex Extension – 15FT
    25FT
    IPFLEXEXT25FT
    IP Flex Extension – 25FT
    50FT
    IPFLEXEXT50FT
    IP Flex Extension – 50FT
    Request Demo

    Request A Product Demo

    Request a personalized demo or speak directly with our sales team today.

    Authorized Vendors
    Download Product Information
    SKU: IPFLEXEXT

    IP Flex Extension

    Technical Specifications
    		 Download
    Download All Resources

    IP Flex Extension

    SKU: IPFLEXEXT

    3-pin IP67-rated FLEX extension cable with locking connectors. Available in four lengths. Ships in bag with header card.

    Features

    Combined Power and Data

    Extends the reach of your setup by carrying both power and data in a single cable.

    Épix System Compatibility

    Designed specifically for use with the Épix Flex 20, ÉPIX Flex Drive, and ÉPIX Flex Boost products.

    Complete Your Rig

    Ensure flawless results with gear designed to complement and complete your professional setup.

      Specifications

      Download Product Specs

      Cable

      • Connector

        3-pin IP FLEX connector

      • Cables Lengths Offered

        5 ft (1.5 m), 15 ft (4.57 m), 25 ft (7.62 m), 50 ft (15.24 m)

      • Cable size

        (3) (SJTW) 16 AWG Stranded

      • Conductors

        Black DC+, White DC-, Green DATA

      • Conductors twisted

        Yes

      • Jacket thickness (outer)

        0.61mm

      • Jacket thickness (each internal wire)

        0.69mm

      • Jacket material

        PVC

      • Jacket type

        Flexible rubber (black)

      • Wire impedance

        0.762 MΩ / kilometer

      • Outer jacket diameter

        8.15mm to 8.45mm

      • Temperature rating

        -40 °F to 221 °F (-40 °C to 105 °C)

      • Shielded

        No

      • IP Rating

        IP67

      What's Included

      • IPFLEXEXT5FT – Cable packed in bag with header card.
      • IPFLEXEXT15FT – Cable packed in bag with header card.
      • IPFLEXEXT25FT – Cable packed in bag with header card.
      • IPFLEXEXT50FT – Cable packed in bag with header card.

      Questions or Concerns?

      Let us know, we’re here to help! Contact Us

      Downloads

      Download All
      Manuals
      IP Flex Extension – Technical Specifications
      		Download

      IP Flex Extension FAQ’s

      Quickly find answers to common questions about setup, operation, and features of the IP Flex Extension
      What is the IP Flex Extension cable used for?

      It is used to extend the distance between ÉPIX Flex 20 lighting fixtures and their power/data source. This single cable conveniently carries both power and data, simplifying your lighting setup.

      Can the IP Flex Extension be used outdoors?

      Yes, it is designed to be fully weatherproof. This high rating protects it from dust and rain, making it reliable for outdoor events and installations in various weather conditions.

      What is special about the IP Flex Extension connectors?

      The cable features secure, locking connectors that prevent it from accidentally unplugging. This ensures a stable and continuous connection for your lighting, even in busy environments.

      If you have any inquiries about our lights, feel free to ask us or visit our help desk for more information.
