COLORado PXL Curve 12

COLORado PXL Curve 12 is a fully pixel-mappable motorized IP65-rated RGBW LED batten with individual control of zoom, tilt and color across twelve independent heads. Basic and advanced operating modes and an extensive library of pre-built effects that includes virtual gobos, movement macros, and foreground/background color control make creating complex and volumetric looks easy. Seamless edge-to-edge mounting maintains pixel pitch between fixtures helping to make runway effects consistent. COLORado PXL Curve 12 speaks DMX, sACN, Art-Net, Kling-Net and RDM.


At a Glance

  • IP65 batten with (12) 45W RGBW LEDs. (12) individually controllable tilting heads with a 5.7° to 36.3°zoom range. Maintains pixel pitch between fixtures.

  • Quiet and quick operation of 200° of tilt of each if (12) heads

  • Quiet and quick operation of (12) individual zoom zones

  • Fully pixel mappable

  • Several built-in effects including virtual gobos and movement macros with foreground and background color control for easy pixel animation effects

  • DMX, SACN, Art-Net, and Kling-Net control for full flexibility

  • RDM Enabled for remote addressing and trouble shooting

  • 5.7° to 36.3° zoom range for variable beam sizes

  • TRUE1 compatible power input/output ports

  • IP65-rated 5 pin DMX and TCP/IP input/output ports

  • IP65-rated USBc software upload port

  • Slotted Omega brackets for easy hanging on truss

Specifications

Optical

  • Light Source: 12LEDs (RGBW) 45 W, (2.96 A) 50,000 hours life expectancy
  • Color Temperature (range): 2700 to 8000 K
  • Beam Angle Spot: 5.7°
  • Beam Angle Flood: 26.8°
  • Beam Angle 50% Zoom: 13.8°
  • Field Angle Spot: 9°
  • Field Angle Flood: 33.9°
  • Field Angle 50% Zoom: 19.2°
  • Cutoff Angle Spot: 9.9°
  • Cutoff Angle Flood: 36.3°
  • Cutoff Angle 50% Zoom: 21.6°
  • Zoom Range: 5.7° to 36.3°
  • Lumens: 5,807 lm
  • Illuminance (Spot) : 38,727 lux @ 5 m
  • Illuminance (Flood) : 1,120 lux @ 5 m
  • Selectable PWM: 600, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 15000 Hz

Dynamic Effects

  • Tilt: 200°
  • Tilt Range: 60°, 180°, 200°
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 20Hz
  • Standalone Color Mixing: No
  • Color Temperature Presets: Yes
  • Dim Modes: 5
  • Built-in Automated Programs: Yes
  • Customizable Programs: Yes
  • Recall Custom Programs: Yes

Construction / Physical

  • Dimensions: 39.49 x 6.65 x 12.76 in (1,003 x 169 x 324 mm)
  • Weight: 76 lb (34.5 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum die-cast, High-Impact flame-retardant polymer, Steel

Connections

  • Power Connection: Edison (Local) plug to Seetronic Powercon IP65
  • Power Input: Seetronic Powercon IP65
  • Power Output: Seetronic Powercon IP65
  • Data Connectors: 5-pin IP65 XLR, Seetronic etherCON IP65
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: Art-Net, sACN, DMX, RDM, Klingnet
  • DMX Channels: 20ch, 53ch, 101ch, 155ch, 179ch
  • Art-Net Channels: 20ch, 53ch, 101ch, 155ch, 179ch
  • sACN Channels: 20ch, 53ch, 101ch, 155ch, 179ch
  • Modes/Personalities: 5 personalities( 20ch, 53ch, 101ch, 155ch, 179ch)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 1 units @ 120 V; 3 units @ 208 V; 3 units @ 230 V
  • Power and Current: 790 W, 6.70 A @ 120 V, 60 Hz
  • Power and Current: 772 W, 3.80 A @ 208 V, 60 Hz
  • Power and Current: 768 W, 3.44 A @ 230 V, 50 Hz
  • Fuse: F12 A, 250 V

Certifications / Qualifications

  • CE, MET, UKCA, FCC
  • IP Rating: IP65, temporary outdoor/wet use
  • Temperature (Ambient): 14 °F to 113 °F (-10 °C to 45 °C)

What's Included

  • COLORADO PXL Curve 12
  • (2) Omega brackets
  • Seetronic Powercon IP65 power cord

Optional Accessories

  • Professional Clamps
  • Neutrik TRUE1 power linking cables
  • 5-pin DMX Cables
  • Ethercon Cables
