W-DMX Micro T-1 TRX G6

Wireless Solutions Micro T-1 Transceiver works with W-DMX and CRMX enabled fixtures to generate a wireless control signal for DMX and RDM protocols. These compact devices can also be set up to transmit or receive W-DMX or CRMX signals to make any fixture or rig wireless. Backward compatible with G3, G4, G4S, and G5 series, and able to operate both W-DMX and CRMX enabled products in G4S Mode. Configurable via Bluetooth with the W-DMX Configurator app. It also features a 5V USB power supply or can be used with (4) AAA batteries for up to 4 hours in transceiver mode and 8 hours in receiver mode. Indicator LEDs easily show signal strength, battery life, and transceiver or receiver mode.






At a Glance

  • Transmit and receive 1 universe of W-DMX, CRMX and RDM protocols

  • Supports the W-DMX Configurator app over Bluetooth (downloadable from app store)

  • Backward compatibility with G3, G4, G4S, and G5 series

  • Can operate both W-DMX and CRMX enabled products in G4S Mode

  • Supports active frequency hopping

  • Power with included 5V USB power supply or (4) AAA batteries (not included)

  • Batteries last for up to 8 hours in receiver mode and 4 hours in transceiver mode

  • Built in indicator lights for signal and battery strength, as well as operation modes

  • Can be used directly with any Maverick or WELL fixtures

  • Can be used to make any lighting system wireless for data

Specifications

Construction / Physical

  • Dimensions: 3.94 x 1.57 x 2.65 in (100 x 40 x 65 mm)
  • Weight: 1.67 lb (800 g)
  • Exterior Color: dark gray
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: 5V micro USB connector (micro B) to wall wart adapter
  • Data Connectors: 5-pin XLR

Control

  • Control Protocol: W-DMX, CRMX, RDM
  • Frequency (operating): # 2.4 GHz
  • Universes per device: 1
  • Number of DMX channels: 512
  • DMX Latency: <5 ms
  • Max universe in coexistence: 16
  • Error correction: yes
  • DMX Fidelity: yes
  • Adaptive Frequency Hopping: Yes
  • W-DMX G3, G4, G4S, and G5 compatibility: Yes
  • Standard range: up to 650 ft (200 m)
  • Internal antenna: Yes
  • Sensitivity (0.1% PER): -97 dBm
  • Modulation method: GFSK

Electrical

  • Input Voltage: 9 VDC 1000 mA, (external power supply: 100-230 V 50/60 Hz)

Battery

  • Battery type: AAA
  • Rechargeable: No
  • Battery Life: 8 hours in receiver mode, 4 hours in transceiver mode

Certifications / Qualifications

  • CE, FCC
  • IP Rating: IP20, dry location
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included

  • W-DMX Micro T-1 TRX G6
  • Micro USB to wall wart adapter
  • User Manual
  • Velcro attachment strap

ORDERING INFO

  • Item Code: 99112032

Downloads

 W-DMX Micro T-1 TRX G6 User Manual
