COLORdash PAR H18 XIP
A rugged, IP65-rated PAR wash with 18 hex-color LEDs that deliver a broad color palette with exceptional precision and smooth 16-bit dimming control.
This die-cast workhorse delivers flicker-free performance for live events, broadcast productions, and architectural installations that demand reliability in any weather condition.
-
Rugged RGBWA-UV LED wash for events where indoor/outdoor flexibility is needed
-
At home in any weather conditions with IP-rated power and DMX connections
-
Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
-
RDM (Remote Device Management) for added flexibility
-
Selectable, smooth dimming curves for eliminating flicker and choppiness in fades
-
Easy-to-read OLED display with password protection and touchscreen interface
-
Advanced optics provide exceptional color mixing and high efficiency
-
Double-bracketed yoke with omega bracket doubles as floor stand
Request A Product Demo
Request a personalized demo or speak directly with our sales team today.
COLORdash PAR H18 XIP
The rugged COLORdash PAR H18X IP RGBAWUV LED wash efficiently delivers a broad palette of subtle to saturated color with beautiful precision. Flawlessly smooth 16-bit fades with four selectable dimming curves. Flicker-free output with multiple PWM frequencies. Punch up a hot pink, mix a delicate pastel, pick a perfectly calibrated Kelvin color temperature, or trigger intense strobe effects. With RDM to remotely choose its DMXÂ personality and an OLED display to easily read its onboard menu, the COLORdash PAR H18X IP offers convenient operation and excellent performance as an IP65-rated all-weather die-cast workhorse at home in any environment, in the rig or on the floor, live or on camera, indoor or out.
Features
Indoor And Outdoor Flexibility
A rugged RGBWA-UV LED wash designed to deliver consistent, high-quality color for events in any environment, from stage productions to architectural facades.
All-Weather Reliability
IP65-rated housing with weatherproof power and data connections ensures dependable performance in rain, dust, or humidity without requiring extra protection.
Flicker-Free On Camera
Selectable Pulse Width Modulation (PWM) frequencies eliminate on-camera flicker, making it an ideal wash light for broadcast studios and livestreamed events.
Remote Device Management
RDM capability allows for remote addressing and configuration, simplifying setup and adjustments for fixtures mounted in hard-to-reach locations.
Smooth Dimming Curves
Four selectable dimming curves provide exceptionally smooth 16-bit fades, ensuring seamless transitions without any visible flicker or choppiness.
Intuitive Onboard Control
A password-protected OLED touchscreen display provides a clear, easy-to-read interface for fast and secure manual adjustments directly on the fixture.
Advanced Optical Design
High-efficiency optics deliver outstanding color mixing from the hex-color source, producing a broad palette from subtle pastels to deeply saturated hues.
Flexible Mounting Options
The included double-bracketed yoke and omega bracket offer versatile rigging options while also functioning as a stable floor stand for uplighting applications.
Complete Your Rig
Specifications
Optical
-
Light Source
18 LEDs (HEX-color RGBAWUV)
-
Color Temperature (range)
2,800 to 10,000 K
-
Color Temperature (at full)
8,439 K
-
Beam Angle
25.4°
-
Field Angle
39°
-
Lumens
5,567 lm
-
Illuminance (total)
1,106 lux @ 5 m
-
Selectable PWM
600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Dynamic Effects
-
Dimmer
Electronic
-
Shutter/Strobe
Electronic
-
Strobe Rate
0 to 20 Hz
-
Standalone Color Mixing
Yes
-
Color Temperature Presets
Yes
-
Dim Modes
4
-
Built-in Automated Programs
Yes
Construction/Physical
-
Dimensions
13.58 x 12.89 x 6.23 in (344.8 x 327.4 x 158.2 mm)
-
Weight
14.4 lb (6.6 kg)
-
Exterior Color
Black
-
Housing Material
Aluminum diecast
-
Accessory Holder/Gel Frame Size
9.5 in (241.3 mm)
Connections
-
Power Connection
Edison (local) plug to Seetronic Powerkon IP65
-
Power Input
Seetronic Powerkon IP65
-
Power Output
Seetronic Powerkon IP65
-
Data Connectors
3- and 5-pin XLR
-
Cable Length (power)
5 ft (1.5 m)
-
Software Update
USB-C
Control
-
Control Protocol
DMX, RDM
-
DMX Channels
6, 8, 9, 13 or 14
-
Modes/Personalities
5 personalities (6ch, 8ch, 9ch, 13ch, 14ch)
Electrical
-
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power Linking
9 units @ 120 V; 16 units @ 208 V; 18 units @ 230 V
-
Power and Current
154 W, 1.25 A @ 120 V, 60 Hz
-
Power and Current
148 W, 0.72 A @ 208 V, 60 Hz
-
Power and Current
150 W, 0.66 A @ 230 V, 50 Hz
Certifications/Qualifications
-
Certifications
CE, MET, FCC, UKCA
-
IP Rating
IP65, temporary outdoor/wet use
-
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories
- Professional Clamps: CTC-50HC, CTC-50HCN
- Riglink TR1 Cables
- Riglink IP DMX cables
What's Included
- COLORdash PAR H18X IP
- Seetronic Powerkon IP65 power cord
- Gel frame
- Omega bracket
- Quick Reference Guide or User Manual
Questions or Concerns?
Let us know, we’re here to help! Contact Us
Downloads
COLORdash PAR H18 XIP FAQ’s
Yes. It features an IP65-rated die-cast aluminum housing and weatherproof Seetronic Powerkon and XLR connections, making it fully protected against rain and dust.
Yes, you can link power for multiple units using the Seetronic Powerkon IP65 power output connection, simplifying cable runs for larger lighting rigs.
Each unit includes a versatile double-bracketed yoke that works with professional clamps and also serves as a sturdy floor stand for uplighting applications.
