LEGACY

COLORdash Par H7IP

COLORdash Par H7IP is an ultra compact, all-weather RGBWAUV LED wash at home in any environment. It delivers a beautifully mixed, soft field of deeply saturated colors. It features a user-friendly OLED full text display. IP rated connections for power and DMX make setup a breeze.


At a Glance

  • Rugged RGBWA-UV LED wash for events where indoor/outdoor flexibility is needed

  • At home in any weather conditions with IP rated power and DMX connections

  • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera

  • RDM (Remote Device Management) for added flexibility

  • Selectable, smooth dimming curves for eliminate flicker and choppiness in fades

  • Easy to read OLED display with password protection and touchscreen interface

  • Advanced optics provide exceptional color mixing and high efficiency

  • Double-bracketed yoke doubles as floor stand

Specifications

Optical

  • Light Source: 7 LEDs (hex-color RGBAW+UV) 10 W, (500 mA), 50,000 hours life expectancy
  • Color Temperature (range): 2800 to 10,000 K
  • Beam Angle: 21°
  • Field Angle: 47°
  • Illuminance (total): 674 lux @ 5 m
  • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

Dynamic Effects

  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 30 Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Built-in Automated Programs: Yes

Construction / Physical

  • Dimensions: 11.02 x 9.44 x 6.06 in (280 x 240 x 154 mm)
  • Weight: 7.8 lb (3.6 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum die-cast
  • Accessory Holder/Gel Frame Size: 6.5 in (165 mm)

Connections

  • Power Connection: Edison(Local plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Data Connectors: 5-pin IP65 XLR
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: DMX, RDM
  • DMX Channels: 6, 8 or 13
  • Modes/Personalities: 3 personalities (6, 8, 13)

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 23 units @ 120 V; 39 units @ 208 V; 42 units @ 230 V
  • Power and Current: 68 W, 0.569 A @ 120 V, 60 Hz
  • Power and Current: 72 W, 0.347 A @ 208 V, 60 Hz
  • Power and Current: 74 W, 0.318 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET
  • IP Rating: IP65, temporary outdoor/wet use
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included

Downloads

 COLORdash Par H7IP User Manual
 COLORdash Par H7IP Quick Reference Guide
 COLORdash Par H7IP CAD Drawings
 COLORdash Par H7IP DMX Chart
 COLORdash Par H7IP Photometrics File
 COLORdash Par H7IP ShowXpress Profile
 COLORdash Par H7IP IES File
 Photometrics Report_COLORdash Par H7IP File
