COMING SOON

COLORado PXL Curve 1

COLORado PXL Curve 1 features motorized pan, tilt and zoom in a compact IP65-rated RGBW LED beam and wash fixture that brings the added punch of dual linear cool and warm white LED strobe cells. Designed for seamless pixel mapping with multiple fixtures, alignment pins maintain pixel pitch while its color blending and rectangular head perfectly match other COLORado PXL models in the rig. Flexible DMX, sACN, and Art-Net control along with RDM and NFC support round out this versatile addition to the COLORado PXL family.

BOOK A DEMO

Pre-order

*PRELIMINARY SPECIFICATIONS ONLY


Specifications

Optical

  • Light Source: 1 LEDs (quad-color RGBW) 120 W, (5 A), 50,000 hours life expectancy
  • Light Source: 160 SMD-LEDs (80 CW, 80 WW), 50,000 hours life expectancy

Dynamic Effects

  • Pan and Tilt: 60°/190°
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized/Manual
  • Strobe Rate: 0 to 25 Hz
  • Color Temperature Presets: Yes
  • Move-in-Black: Yes
  • Dim Modes: 2
  • Dim Curves: 4

Construction / Physical

  • Dimensions: 7.83 x 8.46 x 12.99 in (199 x 215 x 330 mm)
  • Weight: 15 lb (6.8 kg)

Connections

  • Power Input: Seetronic Powerkon
  • Power Output: Seetronic Powerkon
  • Data Connectors: 5-pin IP65 XLR, etherCON
  • Cable Length (power): 5 ft (1.5 m)

Control

  • Control Protocol: [Art-Net, sACN, DMX, RDM, NFC]
  • DMX Channels: 24 or 45
  • Art-Net Channels: 24 or 45
  • Modes/Personalities: 2 personalities (24, 45)
